Summary
Have a wide range of height adjustment
Make the loading and unloading job easy and fast, improve logistic efficiency
Simple and stable operation
Easy for the forklift operation to achieve better connection between warehouse and outdoor
Application
Factories, workshops and warehouses which are especially in the field of food, supermarkets, assembly, logistics, warehousing and etc.
Features
lift materials up and down to achieve goods loading and offloading
Low maintenance rate and easy repair
Scissor Legs are responsible for guiding the platform through different elevation changes
Parameters
Scissor | 200*100*8mm rectangular tube |
Scissor Quantity | Double |
Sealing Element | Japan Brand NOK A505 |
Working Range | ≤1500mm |
Power | 380V/220V |
Oil Pipeline | Double layer steel mesh (Explosion proof) |
Anticollision Block | Laminated belt stamping combined |
Service Life | ≥200,000 times |
Lifting Mode | Point control |
Operating Temperature | -25 ℃ ~ +50 ℃ |
Color | Blue/Grey /Black, could be customized |
Noise | ＜ 50db (±5db) |
