Stable performance
Simple and stable operation
Hydraulic Dock Leveler is the most commonly used and also the most widely used loading and unloading platform
Make the loading and unloading job easy and fast, improve logistic efficiency
Factories, workshops and warehouses which are especially in the field of food, supermarkets, assembly, logistics, warehousing and etc.
Adjust the dock height when the truck height is different with dock
The lip plate is lifted to the rear of the truck to complete the entire action with the dock leveller’s self-weight
Use shot blasting to remove rust and electrostatic spray to enhance corrosion resistance and adhesion
Low maintenance rate and easy repair
Upper Plate | 8mm thickness, anti-skate steel plate |
Swinging Lip | single 16mm thickness, 400mm length |
Support Profile | L-shaped stiffener/14#I Beam |
Sealing Element | Japan Brand NOK A505 |
Working Range | - 300mm to +300mm |
Adjustment Time | Rise Time ≤16S, Fall time time ≤10S |
Power | 380V/220V |
Electric Control Box | 24V weak current control |
Dynamic Loading Capacity | 6000~15000kg |
Static Loading Capacity | 8000~17000kg |
Anticollision Block | Laminated belt stamping combined |
Service Life | ≥200,000 times |
Operating Temperature | -30 ℃ ~ + 50 ℃ |
Color | Blue/Grey/Black, could be customized |
Noise | ＜50db (±5db) |
